Wharfedale EZGO 10 - 100
The new EZGO portable amplifier system from Wharfedale Pro is ideally suited to cover large areas such as classrooms, conference rooms. The system can be configured into different ways with EZGO function modules to suit your specific needs. An optional USB input module and wireless microphone receiver/transmitter module allow you to configure EZGO to suit your specific needs.
EZGO is fully class compliant and requires no drivers when used with modern operating systems, such as MacOSX, Windows XP, Vista and Windows 7 requiring no additional driver software to function.
Wharfedale Pro have produced a pair of highly-specified, utility portable systems — aimed at both the professional and inexperienced user. EZGO 10-100 and EZGO 12-200 are simple to operate, complete packages, comprising a pair of speakers and a mixer/amplifier control unit which lock effortlessly together in a convenient lightweight package. A pole-mount top hat is supplied, and a storage compartment is provided in the mixer/amplifier head unit for speaker and mic cables, AC mains leads etc. No other accessories are required.
The EZGO 10/100 contains two speaker enclosures, each with a 10in woofer and purpose-built electro-dynamic HF drive units, while the 12/200 packs two speakers with 12in drive units and the same HF section, extending the frequency range to 40Hz-20kHz and increasing the power output of its smaller brother from 70W continuous (140W programme) to 125W continuous (250W programme).
SPECIFICATIONS
| MODEL |
EZGO |
| PHYSICAL FEATURES |
| FINISH |
Black |
| CONSTRUCTION MATERIAL |
ABS ,8 mm |
| GRILLE |
Black |
| ENCLOSURE TYPE |
Vented |
| RUBBER FEET |
1 |
| INPUT SENSITIVITY |
| MIC |
Mic in: -44dBu |
| LINE |
Line in: -10dBu |
| MAXIMUM INPUT LEVEL |
| MIC IN |
XLR Female |
| LINE IN |
RCA Jack |
| PEAK INDICATOR |
MIC Peak LED on when input level > 8dB Line Peak LED on when input level > -38dB |
| POWER |
| CONTINUOUS |
70W |
| PEAK |
140W |
| RECEIVER |
| AC POWER SUPPLY |
AC100~240V 50/60Hz |
| SIGNAL TO NOISE RATIO |
>80dB |
| T.H.D. |
<0.1% |
| FREQUENCY RESPONSE |
50Hz~18KHz±3dB |
| PROTECTION |
Short circuit, Thermal protect |
| SYSTEM SPECIFICATION |
| SYSTEM TYPE |
Full range |
| FREQUENCY RESPONSE @ +/- 3DB |
60-18kHz |
| SENSITIVITY 1W@1M |
98 dB |
| PEAK SPL |
122 dB |
| SYSTEM IMPEDANCE |
4 ohm |
| POWER SUPPLY |
DC Jack, 12V/6A IEC Jack, AC100~240V 50/60Hz |
| DRIVER |
| DRIVER SIZE |
5/125 |
| FRAME MATERIAL |
Steel |
| DIMENSIONS (H X W X D) |
360 x 468 x 247 mm |
| NET WEIGHT |
12.2kg |
| GROSS WEIGHT |
14.0kg |
